• - Vial titiriw 0.0002"/10 a wotumi sesa no."
• - V-grooved nnyinaso.
• - ne cross test vial.
• - Robust cast iron nipadua.
• - Sɛ wɔde toto daa master precision levels ho a, wɔyɛ saa level yi na wɔyɛ wɔ tebea a ɛyɛ nwonwa kɛse mu.
•
• Product points ne applications a ɛwɔ bar level:Ahwɛyiye a wɔde di dwuma wɔ bar level .:
• 1.Ansa na wɔde bar level bɛsusu no, ɛsɛ sɛ wɔde ahwɛyiye tew susudua no ho na wɔpopa no ma ɛyow de hwɛ sɛ sintɔ te sɛ nsensanee, nkannare, ne burrs wɔ hɔ anaa.
• 2.Before susuw ne bar level, hwɛ sɛ zero gyinabea no teɛ anaa. Sɛ ɛnyɛ pɛpɛɛpɛ a, ɛsɛ sɛ wɔyɛ nsakrae wɔ level a wotumi sesa no mu, na ɛsɛ sɛ wosiesie level a ɛwɔ hɔ daa no.
• 3.Sɛ woresusuw ne bar level a, ɛsɛ sɛ wokwati nkɛntɛnso a ɔhyew nya. Nsu a ɛwɔ level no mu no nya nkɛntɛnso kɛse wɔ ɔhyew mu nsakrae so. Enti, ɛsɛ sɛ wɔde wɔn adwene si nsa mu ɔhyew, owia hann tẽẽ, ne ahome bɔne a ɛwɔ so no nkɛntɛnso so.
• 4.Wɔ bar level a wɔde di dwuma mu no, ɛsɛ sɛ wɔkenkan wɔ gyinabea a ɛwɔ vertical level no so na ama parallax no nkɛntɛnso so atew wɔ susudua no aba no so.
•

• Product parameter .


• Bar level gauge m bar level gauge nkyerɛkyerɛmu MM: pɛpɛɛpɛyɛ: 0.02mm/m.

Dɛn ne bar level? Nsonsonoe titiriw a ɛwɔ frame levels mu .

​
Bar level yɛ adwinnade a ɛyɛ ketewa, linear precision a wɔayɛ ama susuw tẽẽ, alignment, ne inclination wɔ flat anaa cylindrical surfaces —a ɛyɛ papa ma mfiridwuma mu nneɛma a ahunmu yɛ kakraa bi anaasɛ cylindrical workpieces (sɛ nhwɛso no, pipes, mfiri shafts) hia nhwehwɛmu. Wɔ Storaen no, yɛn bar levels no wɔ rugged cast iron body a ɛwɔ V-grooved base, a ɛma kwan ma wɔde si hɔ a ahobammɔ wom wɔ kurukuruwa no so, ne bubble vial biako a ɛyɛ pɛpɛɛpɛ a ɛbɛma wɔahu sɛnea ɛyɛ anifere (ɛba fam te sɛ 0.02mm/m deviation). Nanso ɔkwan bɛn so na ɛsono wɔ frame level ho? Momma yɛnpaapae nsonsonoe titiriw no mu .:​

1. Nsusuwii & Nsiesiei .​

Bar level: linear, single-axis design a ɛwɔ V-shaped groove wɔ base no ho (critical for gripping cylindrical objects) ne bubble vials biako anaa abien (horizontal/vertical). Ɛyɛ hare na wotumi fa so, ɛyɛ pɛpɛɛpɛ ma mmeae a ɛyɛ den anaasɛ wɔde susuw nneɛma wɔ baabi.​

Frame level (sɛ nhwɛso no, precision frame level): ahinanan, afã anan a ɛwɔ mfiri pii a wɔde yɛ adwuma (anim, akyi, soro, ase), a ɛboa nsusuwii a ɛkɔ soro ne nea ɛkɔ fam nyinaa wɔ plane a ɛyɛ tratraa so. Bultiier nanso ɛyɛ versatile ma complex, multi-surface inspections.​

2. Nsusuwii a wɔde si so .​

Bar Level: Ɛyɛ soronko wɔ cylindrical alignment (sɛ nhwɛso no, hwɛ tẽẽ a mfiri adwinnade akwankyerɛ, paipu installations) ne single-plane flatness. V-groove no hwɛ hu sɛ ɛne shafts kurukuruwa no di nkitaho yiye, na eyi slippage bere a wɔresusuw no fi hɔ.​

Frame level: Ɛdi mu wɔ multi-dimensional flatness checks (a ɛkɔ soro, vertical, squareness) wɔ flat surfaces akɛseɛ te sɛ mfiri bases, construction frameworks, anaa nnua adwuma tables. Ne ntwea anan no ma wonya nsɛm a wɔde gyina hɔ ma anim ne alignment nnwuma a ɛyɛ den.

​
3. Pɛpɛɛpɛ & dwumadie tebea .​

Nnwinnade abien no nyinaa de pɛpɛɛpɛyɛ a ɛkorɔn ma (0.02mm/m gyinapɛn wɔ Storaen), nanso wɔn ahoɔden wɔ nsɛm ahorow a wɔde di dwuma mu .:​

Fa bar level di dwuma bere a wode cylindrical components, rails teateaa reyɛ adwuma, anaasɛ wɔ mmeae a ɛyɛ mmerɛw a adwinnade a ɛyɛ ketewa ho hia.​
Paw frame level (titiriw precision frame level) bere a woresusuw nneɛma a ɛwɔ soro a ɛyɛ tratraa, worehwɛ afã horow a ɛteɛ, anaasɛ ehia bere koro mu horizontal/vertical feedback wɔ adwumayɛbea ahorow, adansi mmeae, anaa CNC mfiri nhyehyɛe ahorow mu.​

4. Storaen nimdeɛ a ɔwɔ wɔ akuw abien no nyinaa mu .​

Wɔ Storaen no, yɛyɛ bar levels ma ahotoso a ɛyɛ den —wɔn cast iron nipadua no ko tia corrosion ne impact, bere a V-groove no fa pɛpɛɛpɛ grinding mu de hwɛ hu sɛ cylindrical fit pɛpɛɛpɛ. Yɛn frame levels, a nea ɛka ho ne premium precision frame level series, a ɛwɔ aluminum frame a ɛyɛ wimhyɛn-grade ne nhyehyɛe abien a ɛyɛ abien ma multi-surface pɛpɛɛpɛ a ɛso bi nni.​

Sɛ́ ebia wuhia portability a bar level anaasɛ versatility a frame level, Storaen industrial-grade nnwinnade no de pɛpɛɛpɛ ne durability wo projects hwehwɛ. Hwehwɛ yɛn range nnɛ na woanya susudua ano aduru a ɛfata ama wo application no.

High-precision bar level: 0.02mm/m pɛpɛɛpɛyɛ ho nkyerɛkyerɛmu .

Wɔ Storaen no, yɛn bar level series no san kyerɛkyerɛ pɛpɛɛpɛyɛ susudua no mu de 0.02mm/m a ɛyɛ pɛpɛɛpɛ a ɛwɔ nnwuma mu —a wɔayɛ no mfiridwuma mu ama nnwuma a mpo deviation a ɛyɛ ketewaa koraa no betumi anya adwuma no nkonimdi so nkɛntɛnso. Saa nkyerɛkyerɛmu yi kyerɛ sɛ yɛn adwinnadeɛ no hunu 0.02mm a ɛkɔ soro wɔ mita 1 a ne tenten yɛ mita 1, a ɛde gyinapɛn a ɛfa alignment a ɛho hia wɔ mfiridwuma, nneɛma a wɔyɛ, ne nsiesie dwumadie mu no si hɔ.​

1. Calibrated bubble vial mfiridwuma .​

Yɛn bar level no pɛpɛɛpɛyɛ no koma ne ne bubble vial a wɔde ahwɛyiye ayɛ no, a wɔde ahwehwɛ a ɛyɛ optical-grade ne nsu a ɛyɛ hyew a ɛyɛ den na ɛyɛe na ama ntrɛwmu mu mfomso no ayɛ ketewaa. Vial biara fa 3-step calibration process mu, hwɛ hu sɛ ahurututu no gyina mfinimfini pɛpɛɛpɛ bere a ɔfasu no yɛ pɛpɛɛpɛ a ɛkɔ soro anaasɛ ɛkɔ fam no. Eyi yi nsusuwii hunu fi hɔ, na ɛma wonya akenkan a emu da hɔ na wotumi san yɛ no mpɛn pii wɔ mmeae a ɛsakrasakra mpo.​

2. Pɛpɛɛpɛyɛ a ɛwɔ V-grooved base .​

Yɛn bar level no wɔ V-shaped groove ground to micron-level tolerances, a ɛhwɛ ma nkitahodi a ɛnyɛ den ne cylindrical surfaces te sɛ mfiri shafts, pipes, anaa rail guides. Groove no 120° anim ne ahwehwɛ-finish ani (RA ≤ 0.8μm) yi slippage ne susudua a enhyia no fi hɔ, na ɛma ɛyɛ nea eye ma nhwehwɛmu a wɔyɛ no tẽẽ wɔ adwuma a ɛyɛ kurukuruwa ho, baabi a pɛpɛɛpɛyɛ nyɛ nea wontumi nsusuw ho.

​
3. rugged construction ma adwumayɛ a ɛyɛ den .​

Wɔde ahyɛ dade a wɔde ayɛ aduru a wɔde ɔhyew ayɛ no mu, yɛn bar level no gyina ɔhyew ntrɛwmu ne mfiridwuma mu nhyɛso ano, na ɛma 0.02mm/m yɛ pɛpɛɛpɛ wɔ -10°C kosi 50°C hyew mu. Solid core design no ma wosow a efi mfiridwuma mu mfiri mu ba no ano brɛ ase, bere a enamel a wɔde kata so a ɛko tia nsu a ɛyɛ hyew no bɔ ho ban fi ngo, nsu a ɛyɛ nwini, ne nsu ho, a ɛho hia kɛse ma bere tenten pɛpɛɛpɛ wɔ adwumayɛbea ahorow a emu yɛ den mu.​

4. Applications a ɛyɛ pɛpɛɛpɛ .​

Efi CNC mfiri adwinnade akwankyerɛ ahorow a ɛne ne ho hyia so kosi sɛnea conveyor rollers anaa pipeline a wɔde si hɔ no yɛ tẽẽ no so no, yɛn bar level a ɛyɛ pɛpɛɛpɛ kɛse no de ahotoso a ɛso bi nni ma. Mfiridwumayɛfo ne mfiridwumayɛfo gye ne 0.02mm/m rating tom ma .:​

Machine adwinnade nhyehyɛe: hwɛ hu sɛ spindle alignment na amma adwuma no asɛe .​
Aerospace component inspection: validating cylindrical part tolerances .​
Nnwinnade a emu yɛ duru siesie: Calibrating hydraulic cylinder shafts ma ɛyɛ adwuma yiye .​

5. Storaen ahofama a ɔwɔ ma pɛpɛɛpɛyɛ .​

Bar level biara gyaw yɛn factory no de traceable calibration certificate, a ɛkyerɛ sɛ ɛne ISO 17025 gyinapɛn ahorow hyia. Yɛde adwinnade biara hyɛ 12-point quality audit ase, a flatness testing, bubble stability checks, ne temperature cycling ka ho, de hwɛ hu sɛ 0.02mm/m specification no yɛ nokware wɔ ne nkwa nna nyinaa mu.​

Sɛ wo dwumadie no hwehwɛ sɛ wosusu sɛ wobɛtumi de wo din ahyɛ mu a, paw Storaen bar level —beaeɛ a 0.02mm/m pɛpɛɛpɛyɛ no nyɛ nkyerɛkyerɛmu bi kɛkɛ, na mmom ɛyɛ bɔhyɛ a ɛfa pɛpɛɛpɛyɛ ho a wɔrensiesie.

Bar Level Applications: Nsusuwso a ɛyɛ adwuma a ɛyɛ kurukuruwa a wɔde susuw nneɛma & v-grooves .

Wɔ mfiridwuma mu susudua mu no, bar levels di mu wɔ pɛpɛɛpɛyɛ nnwuma a ɛfa cylindrical surfaces ne V-shaped structures ho —dwuma a wɔn nhyehyɛe titiriw no yɛ adwuma sen nnwinnade a wɔde di dwuma wɔ ɔkwan a ɛkɔ akyiri so. Wɔ Storaen no, wɔayɛ yɛn bar level series no sɛnea ɛbɛyɛ a wobedi saa nsɛnnennen yi ho dwuma denam pɛpɛɛpɛyɛ ne ahotoso a ɛso bi nni so, na ɛma ɛyɛ nea wɔpɛ ma adwumayɛfo a wɔyɛ adwuma wɔ cylindrical workpices, mfiri adwinnade akwankyerɛ, ne V-grooved components.

1. Cylindrical Workpiece Alignment & Straightness Checks .

a bar level’s defining feature —B-grooved base no—yɛ nkitahodi a ahobammɔ wom, a ɛyɛ den a ɛwɔ nneɛma a ɛyɛ kurukuruwa, te sɛ .:

Machine Tool Shafts: Sɛ ɛne CNC spindle shafts anaa conveyor rollers hyia a, Storaen bar level no hwɛ hu sɛ runout kakraa bi na ɛwɔ hɔ denam micro-tilts (ɛba fam te sɛ 0.02mm/m) a wohu wɔ cylinder no tenten kwan no so no so. V-groove no 120° anim ne asase ani a ɛyɛ pɛpɛɛpɛ (RA ≤ 0.8μm) no ne cylindrical geometry no hyia pɛpɛɛpɛ, na eyi slippage ne susudua mu mfomso ahorow fi hɔ.

Pipeline installations: Wɔ ngo ne gas anaa mfiridwuma piping nhyehyɛe mu no, yɛn bar level no hwɛ sɛ paipu no afã horow no yɛ tẽẽ bere a wɔreboaboa ano no, na esiw misalignment a ebetumi ama flow infficiencies anaasɛ structure stress aba. Ne nhyehyɛe a ɛyɛ ketewaa no hyia ntɛmntɛm wɔ nsu a ɛkɔ nsu mu a ɛyɛ den mu, baabi a nnwinnade a ɛyɛ kɛse ntumi nkɔ hɔ no.

2. V-groove component calibration .

V-grooved structures —a ɛtaa yɛ fixtures, gauges, ne rail systems—no hwehwɛ sɛ wɔyɛ no pɛpɛɛpɛ na wɔyɛ flatness check. Storaen no bar level di mu wɔ ha denam .:

Sɔhwɛ V-groove squareness: Sɛ wode level no si V-grooves abien a ɛne ne ho di asi so (sɛ nhwɛso no, wɔ mfiri adwinnade slides mu) a, ɛda angular deviations adi, na ɛhwɛ hu sɛ nneɛma a ɛwom no ware yiye ma linear motion a ɛyɛ mmerɛw.
Aligning V-guided rails: Wɔ automated manufacturing lines mu no, yɛn bar level hwɛ hu sɛ V-guided rails no yɛ pɛpɛɛpɛ, ɛtew wear a ɛwɔ teaseɛnam a ɛrekɔ so no so na ɛma gyinabea pɛpɛɛpɛ ma robɔt nsa anaa nneɛma a wɔde di dwuma.

3. Kar a ɛyɛ pɛpɛɛpɛ ho nnwuma .

Wɔ nnwuma mu a wɔsusuw tolerances wɔ microns mu .:

Automotive Assembly: Wɔ powertrain instɔlehyɛn mu no, yɛn adwinnade no hwɛ hu sɛ camshafts ne crankshafts no hyia wɔ specification mu, na esiw adwumayɛ ho nsɛm a ɛho ka yɛ den ano wɔ line no mu.

4. Nea enti a storaen bar levels di anim wɔ cylindrical susuw mu .

Yɛn bar level ahorow no ka mfaso atitiriw abiɛsa bom ma saa application ahorow yi .:

Dadeɛ a wɔde ayɛ a ɛyɛ den a wɔde ayɛ: Ɛgyina nsunsuansoɔ ne ɔhyeɛ mu nsakraeɛ ano wɔ adwumayɛbea a ɛyɛ den mu, ɛma ɛyɛ pɛpɛɛpɛ wɔ mfeɛ a wɔde adi dwuma kɛseɛ mu.
Optical-grade bubble vials: Fa akenkan a ɛba ntɛm ara, a emu nna hɔ ma wɔ tebea horow a hann kakraa bi na ɛwom mpo mu, na ɛtew bere a wɔde susuw nneɛma no so 30% sɛ wɔde toto generic levels ho a.
Traceable calibration: Adwinnadeɛ biara de ISO 17025-certified amanneɛbɔ ba, a ɛma awerɛhyem sɛ ne 0.02mm/m pɛpɛɛpɛyɛ du amanaman ntam gyinapɛn a ɛfa nnwuma a ɛho hia ho.

Sɛ́ ebia woreyɛ ade biako a ɛyɛ den anaasɛ worehwɛ mfiridwuma mu nneɛma a ɛyɛ den so no, Storaen bar level no de pɛpɛɛpɛyɛ ne nea ɛtra hɔ kyɛ a ehia na ama cylindrical workpieces ne V-grooved components akɔ so atra tolerance mu no ma. Fa wo ho to adwinnade a wɔayɛ ama nsɛnnennen soronko a ɛwɔ asase kurukuruwa a wɔde susuw nneɛma so no mu, efisɛ wɔ nneɛma a wɔyɛ mu no, curve a ɛyɛ ketewaa koraa no betumi ama nsonsonoe kɛse aba.
